Panel Programming

• Menu 9 - Communications menu
• PBX [not set]
• MSN [not set]
• DT Detection [UK]
• DTMF tone dialling [Yes]
• Enable PSTN line fault monitor [No]
• Monitor service tones [No]
• 3 digit SIA extensions [Yes]
• ISDN point to point [No]
• Enable ISDN line fault monitor [No]
• 3 digit SIA extensions [Yes]
• 200 baud reverse area open/close [No]
• X25 TEI value [2]
• Audio listen in time [180]
• Audio listen in frame time [30]
• Report mains fault [Yes]
• Report line fault [Yes]
• Enable GSM line fault monitor [No]
• Central station
• CS No <1> Enter
• Format No: (Option 7)
• Ph1
• Ph2 [not set]
• Acc No: system account number
• Acc No: area 1 account number
• Bell modem: [Yes]
• Dual reporting [No]
• Listen in [No]
• Disable reporting inhibits [No]
• Reserved [No]
• XSIA Max characters [30]
• X25 account code not important
• Conn type (Option 4)
• suppress FTC for voice reporting [No]
• Retry count [10]
• SIA Area Modifier [Yes]
• X25 D-bit [No]
• Mains Fail Reporting delay [30]
• Enable IP Line Fault Monitor [No]

• AWDGP reporting codes for IMQ [No]

• Menu 29 - Computer Connections menu
• Enable Remote Up\Download [Yes]
• Up/Download if any area armed [Yes]
• Enable Remote Control [Yes or No]
• Remote Control if any area armed
• Use modem Init [No]
• Report Alarms to computer [No]
• Report Access to computer [No]
• Cmp, Cbk, Srv
• Computer Address [0001]
• Security Password [0000000000]
• Security Attempts [255]
• Number of Rings [1]
• Number of Calls [0]
• Answer Machine [No]
• Reserved [No]
• Bell Modem [No]
• Conn Type * (Option 4)
• PC connections authorised [No]
