Panel Programming

• Login to Engineer Mode - Exit /Menu Button + Engineer Code + OK
• Keypad shows 1] Programming and press OK
• Scroll to 1] System and press OK
• Scroll ↓ to 2] Controls and press OK
• Scroll ↓↓ to 3] Communication and press OK
• Scroll ↓↓ to ARC ENABLE and set to 'N' and press OK
• Screen shows 3] Communication and press OK
• Scroll ↓ to FM Enable and set to 'N' and press OK
• Screen shows 3] Communication and press OK
• Scroll ↓↓ to CS ENABLE and set to 'Y' and press OK
• Press Exit / Menu Button 2 twice you are now in the Main Menu
• Scroll ↓↓↓ to 5] Communications and press OK
• Scroll ↓ to 3] Config. SW and press OK
• Screen shows 1] Security and press OK
• Scroll ↓ to 2] Remote ID and press OK
• Modify value to 00000 and press OK
• Screen shows 2] Remote ID Press Exit / Menu Button Press ↓
• Screen shows 2] Call Back. Press OK and ensure NO PHONE NUMBERS are set
• Press Exit / Menu Button x4 times
• Screen shows 5] Communication.
• Now Exit / Engineer Mode 0 and Press OK this saves the data

Trouble shooting

• NOTE: Risco Lightsys has two Communication Menu’s, please check you are in the correct Communication Menu during panel programming.
• Ensure upon initail panel start up that the Language selection is Used otherwise Arc Enable will not show under Communications Menu 3.
• To amend this go to [Programming][System][Settings][Customer] and change it from ‘0EN’ to ‘0UK’ (as it should be for us in the UK)
• By doing this, they will forfeit the entire programming as the panel will invoke a full default for ‘UK’ settings.
• NOTE: Litesys panel integration does not support non zone type alarms such as BV (Burglary Verified).

UDL information for this item can be found here:
