Panel Programming

• Login to panel's Engineer mode
• Go to and select COMMUNICATIONS? and then PROGRAM ARC/SMS?
• Select ARC DEATILS?
• Set Format to WebWayOne [141]
• Set SIA Ack Char [006]
• Set SIA Nack Char [021]
• Valid Areas is Engineer’s choice
• Area Accounts is Engineer’s choice
• Set ARC Account to Site ID/Account No
• Set Redials [003]
• Set Time Out [30]
• Test Calls is Engineer's choice
• Event Types is Engineer's choice

Remote Access Programming

• Go to ‘Set Up Downloading’
• Set Download by (WebWayOne) [4]
• Set Poll Timeout [10]
• Set Modem Init Tmout [060]
• Set Rings To Answer [1]
• Set Comm Tx Timeout [030]
• Set Comm Dial Tmout [030]
• Set UDL Tx Timeout [02]
• Set Redials [03]
• Set Roving Dial to No [0]
• Set Auto Upload to No [0]
• UDL Password is Engineer's choice
• Site Name is Engineer's choice
• Go into Communications Menu and hit "NO "until Advanced Communications
• Yes to enter, Press Yes until ARM PC Tel NO.
• Enter 1111
• Press YES until Program PC 1
• If the Modem Tel No or similar is in the list, enter 1111

Limitations

• Panel ARM feature is not supported by the panel. Believed to be a panel feature fault.

UDL information for this item can be found here:
