• On the Orisec control panel the following willl need to be programmed to integrate to transmit events.

• Enter engineering mode on the panel using the Engineer code, followed by the Manager code.

• Programming Menu
• Navigate to ARC-Setup Menu 17
• Insert or Modify the following
• Account = ARC Account ID
• Protocol = SIA3 or Contract ID
• Dial Seq = 2
• Reported = Set triggers as required
• Area = Set areas as required
• IP Address = Clear value
• IP Port = Clear value
• Exit back to Programming Menu
• Select Com Port Setup Menu 13
• Insert or Modify the following
• Com port = 1
• Mode = WebWayOne SPT/Unit
• Exit Engineering

Technical Notes

• Line fault is through the serial interface, no extra settings are required in either the panel or SPT

UDL information for this item can be found here:

UDL Requirements - Remote Manager V3.4.0.1 & Orisec UDL V3.0.0.4
