Panel Programming

• Engineer Menu 56
• Menu 6 – Int RS232 1
• Select Mode - Direct
• Select Format SIA
• Enter SIA (Option 2)
• Select SIA level 3
• Ensure Trigger 10 is on
• Ensure Trigger 18 is on
• Activate any further triggers which are required
• Enter Account number <_____> (Chip ID)
• Select Comms Setup
• Enter Baud Rate - 57600
• Enter Data Bits - 8
• Enter Stop bits - 1

• Select Parity – No Parity

• Escape to return to Engineering mode.
• Exit Engineer Mode into Day Mode

Galaxy Troubleshooting

• Menu 23: Panel Firmware Version
• Menu 62: Full Set inside Engineering
• Galaxy panels running version V1.4 and below cannot support SIA and are a pins only integration.
• Panel Manfactures Default Codes - USER: 1234 or USER 1,2,3,4,5
• Panel Manfactures Default Codes - ENGINEER: 112233
• Due to Panel Integration on RS232, Line Fault & Fail to Set are only available as SIA Events on a RS485 Integration
• When using this connection method, alarms will not be delivered whilst carrying out UDL

G2 - H/W Priority

• Additional Programming - G2 Models Only
• Select H/W Priority
• 1.Select Telecom [0]
• 2.Select Ethernet [1]
• Use escape to return to Engineer Mode. You need to fully exit Engineering to find the WebWay as a Comms module, we also emulate a Keypad, typically Comms Module 004 and Keypad 015 – varies between panels.

UDL information for this item can be found here:
