Panel Programming

• Enter Engineering Mode.
• Engineer Menu 56
• Select Ethernet Module (Menu 4)
• Select Alarm Reporting (Menu 2)
• Select Format (Menu 1)
• Enter SIA (Option 2)
• Select SIA level 3
• Ensure Trigger 10 is ON
• Ensure Trigger 18 is ON
• Activate any further triggers which are required
• Select Primary IP (Option 2)
• Set IP Address. Acceptable values <127.0.0.1> to <127.0.0.9>
• Set Port Number <50561>
• Select Account Number (Option 4)
• Enter Site ID <_____> (Chip Number)
• Go to Remote Access (Option 3)
• Select Access Period (Anytime)
• Select Mode (Direct Access)
• Escape to return to Engineering mode.
• Exit Engineer Mode into Day Mode
• Panel Connection - as a Telecoms Module
• Engineer Menu 56
• Select External Telecoms Module (Option 5)*
• Select Alarm Reporting (option 2)
• Select Format (Option 1)
• Enter SIA (Option 2)
• Select SIA level 3
• Ensure Trigger 10 is on
• Ensure Trigger 18 is on
• Activate any further triggers which are required
• Select Tel No. 1 (Option 2)
• Set Phone number (01234 567890)
• Select Account Number (Option 3)
• Enter Site ID <_____> (Chip Number)
• Go to Remote Access (Option 3)
• Select Access Period (Anytime)
• Select Mode (Direct Access)
• Older panels may support an Internal Telecom Module (Menu 1) which may be classed as an External Module

Galaxy Troubleshooting

• Menu 23: Panel Firmware Version
• Menu 62: Full Set inside Engineering
• Galaxy panels running version V1.4 and below cannot support SIA and are a pins only integration.
• Panel Manufacturer Default Codes - USER: 1234 or USER 12345
• Panel Manufacturer Default Codes - ENGINEER: 112233

G2 - Specific Programming

• Follow above Panel Programming then complete the below - Galaxy G2 Panels Only
• Select H/W Priority (Option 6)
• 1.Select Telecom [0]
• 2.Select Ethernet [1]
• Use escape to return to Engineer Mode. You need to fully exit Engineering to find the WebWay as a Comms module, we also emulate a Keypad, typically Comms Module 004 and Keypad 015 – varies between panels.
• SPT is running V1.12 or later.

UDL information for this item can be found here:
