Panel Programming- Menu 99

• Select menu 11 - telephone number 1
• Select Tel Number <1>
• Enter Tel Number <01234 567890>
• Select Module
• Select Assist (Off)
• Select Format (Guardall)
• Select Auto Test (Off)
• Select Attempt <1>
• Select Backup <0>
• Select Call Repeat (Off)
• Select GSR <1>
• Select Alarm (On)
• Select Set/Unset (On)
• Select Bypass (On)
• Select Trouble (On)
• Select Log On (On)
• Select Eng On (On)
• Select Reset (On)
• Select Restore (On)
• Press X button twice
• Menu 12 – GSR
• 1. Enter S/N <______> *
• 2. Enter GSR ID <______> **
• 3. Select Enable (Auto)
• 4. Select Callback (Off)
• 5. Select Reset (On)
• 6. Select Unset (On)
• 7. Select Code (On)
• 8. Select Time (On)
• 9. Select Bypass (On)
• 10. Select Soak (On)
• 11. Select Log (On)
• 12. Select Config RD (On)
• 13. Select Config WR (On)
• 14. Select PINs RW (Off)
• 15. Select A. Log Upload <0>
• 16. Select Exit Time <1>
• 17. Select KP Message (On)
• 18. Select Virtual KP (On)
• 19. Press X button once
• Menu 13
• 1. Select the SM (Chosen in Menu 11)
• 2. Set chosen SM to type (serial)
• 3. Set SM Baud rate to <9600>
• 4. Ensure all other SMs and Dialers have the type disabled
• Menu 20
• 1. Select Area ID
• 2. Enter <0>
• 3. Select system <_____>***
• 4. Enter <1>
• 5. Select Area <_____>***
• 6. Press X button four times
• 7. Select 05 to log out

• *GSR Dongle serial number, this number must match in the WebWay SPT.
• **Program the site/Chip ID here. If this configuration option is not found in menu 12, then please check menu 4.
• *** Enter Site/ Chip ID here.
• Important: Please note which Serial module you have connected to (if there are multiple) in order to make sure the panel programming matches.
• Select rings to answer <1>
• Select comm. Tx timeout <030>
• Select ARMPC telephone number (not required)
• Select program PCs <1>
• Select modem telephone number (not required)
• Select signal alarms (No)
• Select signal faults (No)
• Select signal set/unset (No)
• Select signal access code (No)
• Select password (optional UDL password)
• Select redials <03>

IMPORTANT - GSR Dongle Code

• For remote management of the panel the WebWay SPT and the Guardall panel must be programmed with same dongle number as used with the GSR panel software. If remote management is not in use the WebWay and Guardall panel still require a GSR code to send SIA alarms. This can be a generic number, e.g.; 12345. The Webway and Guardall cannot communicate if this number does not match. The dongle number can be entered manually via menu G in the WebWay SPT same manner as for “Auto Take-On” which uses menu D. For site roll outs we can pre populate the WebWay SPT with the GSR code. For more information on this, or and queries on the GSR code please contact support on, 01635 231514 or support@webwayone.co.uk.
• Select stop on success (No)
• Select dial mode (retry same)
• Exit engineering mode and save the configuration

UDL information for this item can be found here:
